1974 Corvette Specs
Body Specs |
|||||
| Wheelbase | 98.0 inches | ||||
| Overhang (Front) | 42.8 inches | ||||
| Overhang (Rear) | 44.7 inches | ||||
| Front Track | 58.7 inches | ||||
| Rear Track | 59.5 inches | ||||
| Length | 185.5 inches | ||||
|
Ground Clearance
Rear Axle Differential to Ground |
6.2 inches | ||||
| Minimum Running Clearance |
4.2 inches
(Exhaust Pipe at X-Member) |
||||
| Overall Height |
47.7 inches (Coupe)
47.8 inches (Convertible) |
||||
| Rocker Panel to Ground (Front) | 7.5 inches | ||||
| Rocker Panel to Ground (Rear) | 7.5 inches | ||||
| Luggage Capacity |
6.1 Cubic Feet (Coupe)
5.0 Cubic Feet (Convertible) |
||||
| Cowl Height | 36.3 inches | ||||
| Windshield Slope Angle | 57° | ||||
| Head Room |
36.2 inches (Coupe)
37.1 inches (Convertible, Soft Top) 36.0 inches (Convertible, Hard Top) |
||||
| Shoulder Room | 47.9 inches | ||||
| Hip Room | 48.8 inches | ||||
| Tire Size | GR70-15B | ||||
| Recommended Tire Inflation | 20 PSI Cold (Front, Rear) | ||||
| Wheels, Regular Production | Size: 15 x 8 | ||||
| Synchronization | All Forward Gears | ||||
| Turbo Hydra-Matic (Automatic) Transmission |
1st Gear 2.48:1
2nd Gear 1.48:1 3rd Gear 1.00:1 Reverse Gear 2.08:1 |
||||
| Lubricant Capacity | 3 Quarts | ||||
| Four Speed M20 Transmission |
1st Gear 2.52:1
2nd Gear 1.88:1 3rd Gear 1.46:1 4th Gear 1.00:1 Reverse Gear 2.59:1 |
||||
|
Close Ratio Four Speed
M21 Transmission |
1st Gear 2.20:1
2nd Gear 1.64:1 3rd Gear 1.27:1 4th Gear 1.00:1 Reverse Gear 2.26:1 |
||||
| Transmission Lubricant Type |
Military MIL-L-2105-B
SAE 80 |
||||
| Lubricant Capacity | Four Speed Manual: 2.5 Quarts | ||||
| Differential Lubricant Type |
Military MIL-L-2105-B
SAE 80 |
||||
| Differential Lubricant Capacity | 3.7 pints | ||||
| Axle Ratio |
195 Horsepower Base Engine
3.08:1, 3.36:1 250 Horsepower L82 Engine 3.55:1, 3.70:1 270 Horsepower 454 Cubic Inch LS4 Engine 3.08:1, 3.36:1 (3.55:1 with M21 Transmission) |
||||
| Transmission Synchromesh | All Four Gears | ||||
| Standard Fuel Tank Capacity | 18 Gallons | ||||
|
Steering Wheel Diameter
(Power, Manual Steering) |
15.0 inches | ||||
| Steering Ratio | 16.1:1 | ||||
| Wheel Turns |
3.4 (Street)
2.92 (Fast) |
||||
| Turning Diameters |
37.0 feet (Curb to Curb)
38.6 feet (Wall to Wall) |
||||
|
|||||
| Model 19467 Convertible |
|
||||
| Model 19437 Sport Coupe |
|
||||
| Shipping Weight: Weight of basic vehicle with regular equipment, including grease, oil, engine coolant to capacity and (4) gallons of gasoline and engine coolant to capacity. | |||||
|
|
|||||
|
|
|||||
| Auxiliary Top (RPO C07) |
+69 lb.
(+59 lb. Front; +10 lb. Rear) |
||||
| Air Conditioning (RPO C60) |
+81 lb. (With Standard, L82 Engines)
(+65 lb. Front; +16 lb. Rear) +87 lb. (With LS4 Engine) (+70 lb. Front; +17 lb. Rear) |
||||
| Power Windows (RPO A31) |
+7 lb.
(+4 lb. Front; +3 lb. Rear) |
||||
| Power Brakes (RPO J50) |
+10 lb.
(+9 lb. Front; +1 lb. Rear) |
||||
|
L82 Engine
250 Horsepower |
+14 lb.
(+11 lb. Front; +3 lb. Rear) |
||||
|
LS4 Engine
270 Horsepower |
+200 lb.
(+178 lb. Front; +22 lb. Rear) |
||||
|
Standard, L82 350 cubic inch Engines
With Turbo Hydra Matic Transmission |
+54 lb.
(+37 lb. Front; +17 lb. Rear) |
||||
|
LS4 Engine
270 Horsepower With Turbo Hydra Matic Transmission |
+45 lb.
(+31 lb. Front; +14 lb. Rear) |
||||
| Power Steering |
+26 lb.
(+25 lb. Front; +1 lb. Rear) With Standard, L82 Engines +28 lb. (+27 lb. Front; +1 lb. Rear) With LS4 Engine |
||||
|
Radio, AM/FM Stereophonic
(RPO U58) |
+18 lb.
(+11 lb. Front; +7 lb. Rear) |
||||
|
Radio, AM/FM Pushbutton
(RPO U69) |
+14 lb.
(+7 lb. Front; +7 lb. Rear) |
||||
|
|
| Type: | V8 |
| Valve Location: | In Head |
| Bore / Stroke: |
4.00" / 3.48" (Standard, L82 350 Cubic Inch)
4.251" / 4.00" (LS4 454 Cubic Inch) |
| Displacement: |
Standard, L82 Engines: 350 Cubic Inches
LS4 Engine: 454 Cubic Inches |
| Compression Ratio: |
8.5:1 (Standard Engine)
9.0:1 (L82 Engine) 8.25:1 (LS4 Engine) |
| Crankshaft Material: | Forged Steel |
| Camshaft Material: | Cast Alloy Iron |
| Oil Pump Type: | Gear |
| Normal Oil Pressure |
32 - 40 psi @ 2,000 RPM
42 - 46 psi @ 2,000 RPM |
| Oil Pressure Gauge | Mechanical |
| Recommended Oil Grade |
Above 20°F: SAE 20W-20, SAE 10W-30, 10W-40
20W-40, 20W-50 0°F to 60°F: SAE 10W, 5W-30, 10W-30, 10W-40 Below 20°F: SAE 5W-20, 5W-30 |
| Fuel Filter | Strainer |
| Fuel Pump | Mechanical |
| Fuel Pressure | 5¼ - 6½ PSI |
| Cooling System Capacity |
350 cubic inch Standard Engine
19 Quarts (with heater) 350 cubic inch L82 Engine 18 Quarts (with heater) 454 cubic inch LS4 Engine 24 Quarts (with heater) |
| Thermostat Type | Choke |
| Radiator Cap Relief Pressure | 15 +/- 1 PSI |
| Battery |
(Standard, L82 Engines)
12 volt - 78 plate
3,250 Watts @ 0° F (LS4 Engine) 12 volt - 90 plate 4,000 Watts @ 0° F |
| Thermostat Opening |
192° - 198° F (Base, LS4 Engines)
177° - 183° F (L82 Engine) |
|
Brakes |
|
| Type | Caliper Disc, Four Wheel Hydraulic |
| Effective Area | 78.1 Square Inches |
| Swept Area | 639.4 Square Inches |
| Disc | Vented |
|
Horsepower |
|
| Standard Engine (350 cubic inch) |
195 hp @ 4,400 RPM;
Torque: 275 lb-ft @ 2,800 RPM |
| RPO L82 (350 cubic inch) |
250 hp @ 5,200 RPM;
Torque: 285 lb-ft. @ 4,000 RPM |
| RPO LS4 (454 cubic inch) |
270 hp @ 4,400 RPM;
Torque: 380 lb-ft @ 2,800 RPM |
|
Ignition System |
|
| Coil |
Delco-Remy Base, L82 Engine: 1115270;
LS4: 1115287 |
| Coil current rating |
4 amps (engine stopped)
1.8 amps (engine running) |
| Breaker Gap | .019" |
| Ignition Timing Centrifugal Advance |
Distributor | 1112247 | Base Engine
Start: 0° @ 800 - 1,200 RPM Intermediate: 9 - 13° @ 2,400 RPM Maximum: 16 - 20° @ 4,200 RPM Distributor | 1112544* | Base Engine Start: 0° @ 850 - 1,200 RPM Intermediate: 13 - 15° @ 2,400 RPM Maximum: 20 - 24° @ 4,200 RPM Distributor | 1112150 | L82 Engine Start: 0° @ 1,000 - 1,400 RPM Intermediate: 10 - 14° @ 2,200 RPM Maximum: 18 - 22° @ 5,000 RPM Distributor | 1112114 | LS4 Engine Start: 0° @ 850 - 1,300 RPM Intermediate: 9 - 13° @ 2,400 RPM Maximum: 16 - 20° @ 4,200 RPM |
| Ignition Timing Vacuum Advance |
Distributor | 1112247 | Base Engine
Start: 0° @ 5 - 7 inches Hg Maximum: 13.5 - 20° @ 13.5 inches Hg Distributor | 1112150 | L82 Engine Start: 0° @ 5 - 7 inches Hg Maximum: 13.5 - 20° @ 12 inches Hg Distributor | 1112114 | LS4 Engine Start: 0° @ 5 - 7 inches Hg Maximum: 18.5 - 21.5° @ 15 inches Hg Distributor | 1112544* | Base Engine Start: 0° @ 5 - 7 inches Hg Maximum: 13.5 - 16.5° @ 13.5 inches Hg |
| Timing |
Base Engine: 8° BTC @ 900 RPM (Manual)
Base Engine*: 4° BTC @ 900 RPM (Manual) 8° BTC @ 600 RPM (Automatic) L82 Engine: 8° BTC @ 900 RPM (Manual) 8° BTC @ 700 RPM (Automatic) LS4 Engine: 10° BTC @ 800 RPM (Manual) 10° BTC @ 600 RPM (Automatic) |
| *Pertains to Engines Used in California | |
| Spark Plug | ACR44T (350, 454 Cubic Inch Engines) |
| Spark Plug Thread | 14 mm. |
| Spark Plug Torque | 15 lb.-ft. |
| Spark Plug Gap | .033 - .038 inch |
| Firing Order | 1-8-4-3-6-5-7-2 |
1974 Corvette Options
| RPO | Description | Production | Price |
| * | Custom Interior Trim | 19,959 (53.22%) | $154.00 |
| Optional Rear Axle Ratios | 1,219 (3.25%) | $12.00 | |
| A31 | Power Windows | 23,940 (63.84%) | $86.00 |
| A85 | Custom Shoulder Belts (standard with coupe) | 618 (1.65%) | $41.00 |
| C07 | Auxiliary Hardtop (for convertible) | 2,612 (6.96%) | $267.00 |
| C08 | Vinyl Covering (for auxiliary hardtop) | 367 (0.98%) | $329.00 |
| C50 | Rear Window Defroster | 9,322 (24.86%) | $43.00 |
| C60 | Air Conditioning | 29,497 (78.65%) | $467.00 |
| FE7 | Gymkhana Suspension | 1,905 (5.08%) | $7.00 |
| J50 | Power Brakes | 33,306 (88.81%) | $49.00 |
| L82 | 350 cu. in. 250hp Engine | 6,690 (17.84%) | $299.00 |
| LS4 | 454 cu. in. 270hp Engine | 3,494 (9.32%) | $250.00 |
| M21 | 4-Speed Manual Transmission, close ratio | 3,494 (9.32%) | n/a |
| M40 | Turbo Hydra-Matic Automatic Transmission | 25,146 (67.05%) | n/a |
| N37 | Tilt-Telescopic Steering Column | 27,700 (73.86%) | $82.00 |
| N41 | Power Steering | 35,944 (95.85%) | $117.00 |
| QRM | White Stripe Steel Belted Tires, GR70x15 | 9,140 (24.37%) | $32.00 |
| QRZ | White Letter Steel Belted Tires, GR70x15 | 24,102 (64.27%) | $45.00 |
| U05 | Dual Horns | 5,258 (14.02%) | $4.00 |
| U58 | AM-FM Radio, stereo | 19,581 (52.21%) | $276.00 |
| U69 | AM-FM Radio | 17,374 (46.33%) | $173.00 |
| UA1 | Heavy Duty Battery (standard with LS4) | 9,169 (24.45%) | $15.00 |
| UF1 | Map Light (on rearview mirror) | 16,101 (42.93%) | $5.00 |
| YF5 | California Emission Test | n/a | $20.00 |
| Z07 | Off Road Suspension and Brake Package | 47 (0.13%) | $400.00 |
|
Total Production:
37,502
Notes: Base Corvette Coupe with 350 cu. in. 195 hp engine and wide ratio four speed manual transmission: $6,001.50. |
|||
Colors
| Code | Exterior | Quantity | Interior | Soft Top | Wheels |
| 10 | Classic White | n/a | Black / Dark Blue / Dark Red / Neutral / Saddle / Silver | Black / White | Silver |
| 14 | Silver Mist | n/a | Black / Dark Blue / Dark Red / Neutral / Silver | Black / White | Silver |
| 17 | Corvette Gray | n/a | Black / Dark Blue / Dark Red / Neutral / Saddle / Silver | Black / White | Silver |
| 22 | Corvette Medium Blue | n/a | Black / Dark Blue / Silver | Black / White | Silver |
| 48 | Dark Green | n/a | Black / Neutral / Saddle / Silver | Black / White | Silver |
| 56 | Bright Yellow | n/a | Black / Neutral / Saddle / Silver | Black / White | Silver |
| 68 | Dark Brown | n/a | Black / Neutral / Saddle / Silver | Black / White | Silver |
| 74 | Medium Red | n/a | Black / Dark Red / Neutral / Saddle / Silver | Black / White | Silver |
| 76 | Mille Miglia Red | n/a | Black / Dark Red / Neutral / Saddle / Silver | Black / White | Silver |
| 80 | Corvette Orange | n/a | Black / Neutral / Saddle / Silver | Black / White | Silver |
